M-2.5 Supercritical CO2 Extractor
M-2.5 Supercritical CO2 Extractor
MANUAL MACHINE SPECIFICATIONS • Sub/Supercritical CO2 Extraction Machine • 5,000 psi • 2.5L Extraction Cylinder (one) • 2.5L Collector (one) • CRN & PED Numbers Available Upon Request • GMP Compliant The extraktLAB benchtop extractor, the M-2.5, is designed with the R&D and small batch producer in mind. The extractor unit features a wide range of extraction temperatures and pressures to aid in the production of unique extracts and development of novel extraction methods. The unit also features an optional secondary pump to enable the introduction of a co-solvent to maximize versatility and methods development range. The system comes equipped with a touchscreen HMI panel for data logging temperature and pressure conditions.
M-2.5 Supercritical CO2 Extractor
- Sub/Supercritical CO2 Extraction Machine
- 5,000 psi
- 2.5L Extraction Cylinder (one)
- 2.5L Collector (one)
- CRN & PED Numbers Available Upon Request
- GMP Compliant
- Footprint: 6 ft2
- Dimensions: 30”x27”x33” (LxWxH)
- Sound Pressure: 50dB
- Electrical: 208-230/380V, 30A, 1 ph, 50/60 Hz
- Compliance: UL 508A Motor Starter, No Panel, ASME Section 2 VII Div 2
- Wetted Materials: FDA Approved Stainless Steel, 316, 304, 17-4 PH Stainless Steel, PTFE, PEEK, Peroxide Cured Buna-N consumable seal Warranty: 12 months
