Fusion 4000-X
Fusion 4000-X
The Fusion 4000-X independent dual-channel infuse and withdraw syringe pump – built with 2 separate pump drives capable of independent pulseless, reproducible rates and movement. Programmable multi-step and cycle mode that allows users to input complex flow profiles or perform flow cycling from a computer Labview or the pump itself. This syringe pump system also can be expanded with a 2-syringe push and pull rack attachment to increase the total syringe capacity to four.
Fusion 4000-X
| Mode | Infuse/Withdraw |
| Accuracy | ± < 0.35% |
| Reproducibility | ± < 0.2% |
| Syringe Size (Min/Max) | 0.5µL to 100mL |
| Syringe Type | Plastic, Glass, and Stainless Steel Syringe Type Chart |
| Syringe Flow Rates | See Syringe Library for Min & Max Flow Rates |
| Minimum Flow Rate | .0001 µL/min (with 0.5 µL syringe) |
| Maximum Flow Rate | 170.5 mL/min (with 100mL syringe) |
| Linear Force | 85lb (38.5kg) |
| Maximum Pressure | See Max Pressure |
| Display | 4.3 inch LCD Glass Touch Screen |
| Connectivity | USB-B, RS232, RS485 and TTL Ports |
| System Dimensions | 11 x 12 x 4.9 inches (28 x 31 x 13 cm) |
| Power | 110/220 VAC |
| Weight | 19 lbs (8.6kg) |
| Motor Drive | 1.8˚ MicroStepper Motor |
| Step Resolution | 0.0293 µm/step |
| Operating Temperature | 4°C to 40°C (40°F to 104°F) |
| Storage Temperature | -10°C to 70°C (14°F to 158°F) |
| Humidity | 20% to 80% RH, non-condensing |
| Installation Category | II |
| Regulatory Compliance | CE, RoHS, REACH, ETL |
